Product Introduction:
High Transparency, High Cleanness, High heat stability, Great optical property, Excellent flatness Insoluble in Common solvents and petrol, Excellent Insulation performance. Mainly used for LCD diffuser film and LED lighting product.
Product Data Sheet:
NOMINAL THICKNESS | 36～100μm | METRIC UNITS | ||
Property | TEST METHOD | UNIT | TEST VALUE | |
AVERGE THICKNESS TOLERANCE | ASTM D374 | % | ±2 | |
TENSILE STRENGTH ≥ | MD | ASTM D882 | Mpa | 195 |
TD | 220 | |||
ELONGATION ≥ | MD | ASTM D882 | % | 170 |
TD | 125 | |||
HEAT SHRINKAGE ≤ | MD | ASTM D 1204 150℃/30min | % | 1.2 |
TD | 0.15 | |||
Haze ≤ | ASTM D1003 | % | 1.8 | |
WETTING TENSION | ASTM D2578 | dyne/cm | 56 | |
TRANSMITTANCE | ASTM D1003 | % | 89.3 | |
Explain:
1.Wetting tension test is only applicable to corona treated film.
2.The results should, however, only be regarded as a general guide to material properties and not as a guarantee.
